㈠Feature:

 (Standard Resistance Range):10Ω-2MΩ

（Resistance Tolerance):±5% ,±10%

（Terminal Resistance):≤1%R or 2Ω

（Contact Resistance Variation):≤3%R or 3Ω

（Insulation Resistance):R1≥1GΩ

（Winthstand Voltage):101.3kPa 600V 8.5kPa 315V

（Effective Electrical Travel): 30±2(cycles)

㈡Power(W): 0.5=0.5W

㈢Tolerance Range: J=±5%,K=±10%

㈣Resistance Range(Ω):10Ω~2MΩ

㈤TCR PPM/℃:±100ppm/℃,±250ppm/℃
