㈠Characteristics：

 Ⅰ Rated DC Current: The DC current when the inductance
    becomes 10% lower than its initial value or DC current when
    temperature of coil is increased to 40 ℃ (Ta-25℃）
    The smaller one is defined as Rated DC Current.
 ⅡOperating temperature range: -40 ～ 125°C

㈡Features：

 ⅠHigh power, High saturation inductors
 ⅡIdeal inductors for DC-DC converters in notebook
   computer, PDAs, Step-up or step-down converters,
   flash memory programmers, etc.
 ⅢPD1608 used ceramic base with gold-platings.
 ⅣThe others used LCP plastic base

㈢Applications：

  ⅠPower Supply For VTRs..
  ⅡLCD Televisions
  ⅢPersonal Computers.
  Ⅳ Handheld Communication
  Ⅴ DC/DC Converters, etc.

㈣Dimensions( AxBxC）：

  1608: 6.60×4.45×2.92,3308: 12.95×9.40×3.00，3316: 12.95×9.40×5.21

  3340: 12.95×9.40×11.43,5022: 18.54×15.24×7.11

㈤Tolerance：

  M:±20%

㈥Inductance：

  1R0= 1.0µH,470= 47µH,101= 100µH
