㈠Characteristics：

 Ⅰ ⅠSaturation Rated Current :The current when the inductance
     becomes 30%lower than its initial value.(Ta=25° C)
 ⅡOperating temperature range: -40 ～ 125°C

㈡Features：

 ⅠMiniature surface mount design
 ⅡHigh power, High saturation inductors
 ⅢVery low resistance
 ⅣMaximum power density
 ⅤIdeal inductors for DC-DC converters
 ⅥAvailable on tape and reel for auto surface mounting

㈢Applications：

 ⅠNotebook Computers.
 ⅡHandheld Communications
 ⅢLCD Televisions.
 ⅣPower Supply For VTRs
 ⅤDC/DC Converters, etc.

㈣Dimensions( AxBxC）：

  1608: 7.5×5.2×3.2,1813: 8.89×6.4×5.0,3316: 13.21×9.91×6.35
  4920: 19.4×13.3×6.8,5022: 22.35×16.26×8.0

㈤Tolerance：

  M: ±20%,N: ±30%,P: +40%-20%

㈥Inductance：

  1R0= 1.0µH,470= 47µH,101= 100µH
