㈠Introduction：

     Rod and Tube Resistors are manufactured from a carefully selected mixture of clays, alumina and carbon.
  After blending,the material is extruded into the required shape and then fired,in a controlled atmosphere,

  at hightemperature.
     Aluminium  is then flame sprayed onto the barrel  surfaces(as standard)  to  provide electricalcontact.
     Alternative metallised contacts and corona shielded terminals are also available.
     Rod and  Tube  Resistors are available with Outside Diameters ranging from 10mm to 50mm and in Lengths
  up to 600mm..

㈡Features：

    Ⅰ.High Voltage
    Ⅱ.High Energy
    Ⅲ.Non-Inductive
    Ⅳ.Wide Range of Geometries
    Ⅴ.Custom Solutions Readily Available

㈢Applications：

    Ⅰ.Dummy Aerial Loads
    Ⅱ.Overvoltage Protection
    Ⅲ.Capacitor Discharge

㈣Power Rating:
    10W、20W、24W、55W....300W
㈤Tolerance:
    J=±5%，K=±10%，M=±20%
㈥Resistance Range
    22-2.2K
㈦T.C.R:
    -1500ppm /℃≤T.CR≤0
