Features:

  SP, with the inner and outer surfaces coated with a
special glass, features higher thermal resistance and larger
electric power capacity for the compact volume. Unlike
conventional wire wound resistors, the volumetric
resistor will provide superior stability versus frequency
and higher durability against transient voltage. Further,
SP can be used in water, which enables the resistor to
be suitable for the application with large current as well
as high frequency circuit.

Applications:

  . power supply circuits

  .Dummy loads,
  .circuits for protecting against parasitic oscillation

  .PT protection
  .High-frequency circuits

  .Accelerators
  .Other high-current circuits

  .Surge absorption,
  .Other applications:far-infrared heaters,microwave absorber

 . Ultrasonic devices

Type: SP SERIES
Power Rating: 3=3W、5=5W、10=10W、、、、
Tolerance: K=±10%、 M±20%
Resistance Value:10R0=10Ω 、100R0=100Ω
