㈠Features:

High Voltage Resistors HVT Series combine proprietary non-inductive  resistance system and design to achieve low temperature coffcient, low  voltage coffcients, high stability and increased high operating voltages.

Precision High Voltage Resistors HVT Series are designed to meet the  demanding requirements of TWT power supplies, electron microscopes,  X-ray systems, high resolution CRT displays and geophysical instruments.

㈡Power Rating:
   1W,2.5W,3.3W,4.5W,6.5W,9W

㈢Tolerance:
  B=±0.1%,C=±0.25%,D±0.5%F=±1%,G=±2%,J=±5%,K=±10%
㈣Resistance Range
  1K-2G

㈤T.C.R.

  ±25ppm/℃  ±50ppm/℃  ±100ppm/℃  ±250ppm/℃
